| Display Type | LCD with Backlight |
| Display Configuration | 7 Digits |
| Electrical Connection | 1Ø - 2W |
| Type of Output | Two Pulse Outputs |
| Communication Protocol | RS485 and MODBUS RTU |
| Features | Self Powered, 100A Direct Connection, Bi - directional Import / Export Energy measurement, Two Pulse Outputs, Power (Active / Reactive/Apparent) |
| Power Consumption | 8VA Max |
| Input Current Range | 5A AC (Min - 10mA, Max - 100A) |
| Supply Voltage | 176 to 276V AC (Self – Powered), (45 to 65Hz) |
| Mounting Type | Din Rail |
| Size | 35 x 90mm |
| Certification | CE, MID |
